Prezzo: € 117,90 +IVA
Disponibilità: 0
DESCRIPTION SPECIFICATIONS
KSM48R40BS4TMM-32HMR
32GB 1Rx4 4G x 80-Bit
PC5-4800 CL40 Registered EC8 288-Pin DIMM
Continued >>
FEATURES
Kingston's KSM48R40BS4TMM-32HMR is a 4G x 80-bit (32GB)
DDR5-4800 CL40 SDRAM (Synchronous DRAM), 1Rx4, ECC,
memory module, based on twenty 4G x 4-bit FBGA components.
The SPD is programmed to JEDEC standard latency DDR5-4800
timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact
fingers. The electrical and mechanical specifications are as follows:
CL(IDD)
Row Cycle Time (tRCmin)
Refresh to Active/Refresh
Command Time (tRFCmin)
Row Active Time (tRASmin)
Row Precharge Time (tRPmin)
UL Rating
Operating Temperature
Storage Temperature
40 cycles
48ns(min.)
295ns(min.)
32ns(min.)
16ns(min.)
94 V - 0
0o
C to +95o
C
-55o
C to +100o
C
• Power Supply: VDD = 1.1V Typical
• VDDQ = 1.1V Typical
• VPP = 1.8V Typical
• VDDSPD = 1.8V to 2.0V
• On-Die ECC
• x80 ECC (x40, 2 independent I/O sub channels)
• 32 internal banks
• Hard/Soft Post Package Repair
• Sideband access with I3C/I2C
• PCB: Height 1.23” (31.25mm)
• RoHS Compliant and Halogen-Free
