| Ingrandisci immagine |
Prezzo: € 19,90 +IVA
Disponibilità: 0
Interfaccia 3 10/100Mbps RJ45 LAN Ports
1 10/100Mbps RJ45 LAN/WAN Port
1 RJ11 Port
Tasto WPS Button
RESET Button
Power ON/OFF Button
Alimentatore esterno 9VDC/0.6A
Standard IEEE IEEE 802.3, 802.3u
Standard VDSL2 ITU-T G.993.2
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)
Dimensioni ( L x P x A ) 181.6 x 129.7 x 36.2mm
Tipo di antenna Omni directional, Fixed
Guadagno antenna 2 x 5dBi
CARATTERISTICHE WIRELESS
Standard wireless IEEE 802.11b, 802.11g, 802.11n
Frequenza 2.400-2.4835GHz
Potenza di trasmissione <20dBm(EIRP)
Sicurezza wireless 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryptions, Wireless MAC Filtering
CARATTERISTICHE SOFTWARE
QoS (Quality of Service) WMM, Bandwidth Control (IP QoS)
Sicurezza NAT Firewall, SPI Firewall, DoS Protection, IP & MAC Binding, Service Filtering, Access Control, Parental Controls
Modalità operative VDSL/ADSL Modem Router, Wireless Router,
Gestione Web Based Configuration (HTTP), Remote management, CWMP(TR-069), Web Based Firmware Upgrade, Diagnostic Tools
VPN pass-through IPSec VPN
Protocolli Supports IPv4 and IPv6
Protocolli ATM/PPP PPPoE (RFC2516)
PPPoA (RFC 2364)
MER\IPoE (RFC 1483 Routed)
IPoA (RFC1577/2225)
Bridge (RFC1483 Bridge)
Caratteristiche avanzate Parental Controls, Network Address Translation(NAT), Port Mapping(Grouping), Static Routing, DNS Relay, DDNS, IGMP V1/V2/V3
APP Tether App
NAT Virtual Server, Port Triggering, DMZ, ALG, UPnP
ALTRO
Certificazione CE, RoHS
Contenuto della confezione TD-W9960
External DSL Splitter
RJ-11 DSL Cable
RJ-45 Ethernet Cable
Quick Installation Guide
Power Adapter
Requisiti di sistema Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10,
Mac OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Subscription with an internet service provider (for internet access)
Ambiente Operating Temperature: 0℃~40℃(32℉~104℉)
Storage Temperature: -40℃~70℃(-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
