Prezzo: € 38,50 +IVA
Disponibilità: 0
Specification
CPU
AMD Socket AM2+ / AM2 Processors
AM2 Phenom FX(2000MT/s)/Phenom(2000MT/s)/Athlon64 FX/Athlon64 X2/Athlon64/Sempron processors
AMD Cool 'n' Quiet™ Technology
AMD64 architecture enables simultaneous 32-bit and 64-bit computing
AMD Live!™ Ready
Chipset
NVIDIA Geforce 7025/nForce 630a
System Bus
2000/1600 MT/s
Memory
2 x240-pin DIMM, Max. 4 GB, DDR2 1066/800/667/533 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
Expansion Slots
1 x PCIe x16
2 x PCI
VGA
Integrated Nvidia® Geforce®7Series Shader model3.0 DirectX 9 graphics processor
Maximum shared memory of 256 MB
Supports RGB with max. resolution 1920 x1440 (@70Mhz*32bpp/75Mhz*16bpp)
Supports DVI-D with max. resolution 1920 x1200 (@60Mhz)
Supports DVI-D with HDCP compliant with max. resolution 1920 x 1080*
Storage
1 xUltraDMA 133/100
4 xSATA 3 Gb/s ports
Support RAID 0,1,5,10,JBOD
LAN
Phy Gigabit LAN
Audio
VIA VT1708B/S High Definition Audio 8 -Channel CODEC
USB
10 USB 2.0 ports
Overclocking Features
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz to 300MHz at 1MHz increment
-Adjustable CPU Voltage at 0.025V increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
Special Features
ASUS MyLogo 2
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS Q-Fan
Back Panel I/O Ports
1 x DVI
1 x VGA
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN(RJ45) port
4 x USB 2.0/1.1
8 -Channel Audio I/O
Internal I/O Connectors
3 x USB connectors supports additional 6 USB 2.0 ports
1 x Floppy disk drive connector
1 x IDE connector
1 x LPT connector
1 x S/PDIF Out connector
1 x4-pin ATX 12V Power connector
24-pin EATX Power connector
CPU / Chassis Fan connectors
Front panel audio connector
COM connector
Chassis Intrusion connector
System Panel
CD audio in
BIOS
8 Mb Flash ROM
DMI 2.0
AMI BIOS
PnP
WfM 2.0
SM BIOS 2.5
Manageability
WfM 2.0,DMI 2.0,WOR by Ring, PME Wake Up
Accessories
User's manual
1 x I/O Shield
1 x UltraDMA 133/100/66 cable
1 x Floppy disk drive cable
1 x SATA cable
1 x SATA power cable
Support Disc
Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS LiveUpdate Utility
Form Factor
uATX Form Factor
9.6 inch x 8.3 inch ( 24.4 cm x 21.1 cm )
