Specifications
CPU
Intel® Socket 775 for Intel® Core™2 Extreme/Core™2 Quad/Core™2 Duo/Pentium® dual-core/Celeron® dual-core/Celeron® processors
Intel Hyper-Threading Technology ready
Support Enhanced Intel SpeedStep Technology (EIST)
Supports Intel® 45nm multi-core CPU
Chipset
Intel® G43 Intel ICH10
Front Side Bus
1333/1066/800 MHz
Memory
2 x DIMM, Max. 8 GB, DDR2 1066(O.C.)/800/667 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
Please refer to www.asus.com or user manual for Memory QVL.
When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
Expansion Slots
1 x PCIe x16
1 x PCIe x1
2 x PCI
Supports PCIe 2.0 / 1.0 Architecture
VGA
Integrated Intel GMA4500 graphics
Maximum shared memory of 1759MB
Supports DVI-D with HDCP compliant with max. resolution 1900x1200 (@ 60Hz)
Supports DP with max. resolution 2560*1600 (@ 60Hz)
Supports RGB with max. resolution 2048 x 1536 (@75Hz)
Supports Microsoft® DirectX® 10
Dual VGA output support:
DVI & DP
DVI & RGB
RGB & DP
Storage
Southbridge
1 xUltraDMA 133/100/66
6 xSATA 3 Gb/s ports
LAN
PCIe Gigabit controller featuring AI NET 2
Audio
VT1708B, 8 -Channel High-Definition Audio CODEC
Support Jack Detection and Multi-streaming
USB
12 USB 2.0 ports (6 ports at mid-board,6 ports at back panel)
ASUS Unique Features
ASUS Express Gate
AI NET2
ASUS Q-Fan
ASUS CrashFree BIOS 3
ASUS MyLogo 2
ASUS EZ Flash 2
Overclocking Features
SFS (Stepless Frequency Selection) from 200MHz to 600MHz at 1MHz increment
Adjustable CPU Voltage at 0.025V increment
- ASUS C.P.R.(CPU Parameter Recall)
Back Panel I/O Ports
1 x PS/2 Keyboard
1 x DVI
1 x DP
1 x VGA
1 x RJ45 port
6 x USB 2.0/1.1
8-channel Audio I/O
Internal I/O Connectors
3x USB connector (6ports)
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Power Fan connector
Front panel audio connector
1 x S/PDIF Out Header
Chassis Intrusion connector
CD audio in
1 x 24-pin EPS12V Power connector
4-pin ATX 12V Power connector
System Panel connector
BIOS
8 Mb Flash ROM
DMI 2.0
AMI BIOS
PnP
WfM 2.0
SM BIOS 2.3
ACPI 2.0a
Manageability
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Accessories
UltraDMA 133/100/66 cable
1 x Serial ATA cables
1 x Serial ATA power cable
I/O Shield
User's manual
Support Disc
Drivers
Express Gate
ASUS PC Probe II
ASUS LiveUpdate Utility
Form Factor
uATX Form Factor
9.6 inch x 9 inch ( 24.4 cm x 22.9 cm )
