| Ingrandisci immagine |
Prezzo: € 62,90 +IVA
Disponibilità: 0
Specification & Details
Heatsink Specification
Dimension ( with fan ) L142.4 mm x W140 mm x H168.3 mm
Weight ( with fan ) 1282 g
Weight ( without fan ) 970 g
Heat pipes 6mm heatpipe x 7 units
Front Fin T = 0.4 mm ; Gap = 2.4 mm
Front Fin Pcs 42 pcs
Rear Fin T = 0.4 mm ; Gap = 1.8 mm
Rear Fin Pcs 53 pcs
Copper Base C1100 Pure copper nickel plated
Distance From Center 40 mm
RAM Height Limit 30 ~ 35 mm ( Fan position adjustable )
TDP 250 W+
Fan Specification
XF140
Dimension L140 mm x W140 mm x H25.4 mm
Weight 156 g
Rated Speed 700 ~ 1300 RPM ±10 %
Noise Level 19 ~ 23 dBA
Air Flow 76 CFM
Air Pressure 1.44 mmH2O
Ampere 0.16 A
Motherboard Compatibility
2066, 2011(-3), 1150, 1151, 1155, 1156<
FM1, FM2/+, AM2/+, AM3/+, AM4
What's In The Box
R1 Ultimate x 1
MultiSeg™ Backplate for Intel x 1
AM4 Screw Pillar x 4
Intel Mounting Bar x 2
AM4 Mounting Plate x 1
Thumb Screw Caps x 4
Screw Pillars x 4
LGA 2011 Screw Pillars x 4
XF140 Wireclips x 2
XT140 Wireclips x 2
Acoustic Vibration Absorbers x 4
CP-7 x 1
Alcohol Pad x 1
L-Screwdriver x 1
Installation Guide x 1
PWM Y-Cable x 1
