Prezzo: € 64,00 +IVA
Disponibilità: 1
Model Number
MCB-NR200P-KGNN-S00, MCB-NR200P-WGNN-S00
Series
MasterBox Series
Size
Mini ITX
Available Color(s)
Black, White
Materials
Steel, Plastic, Mesh, Tempered Glass
Dimensions (L x W x H)
376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions
Volume (exlc. Protrusions)
18.25L
Motherboard Support
Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H)
Expansion Slots
3
5.25" Drive Bays
0
3.5" Drive Bays
1 (Max. 2)
2.5" / 3.5" Drive Bays (combo)
1
2.5" Drive Bays
2 (Max. 3)
I/O Panel
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
Pre-installed Fans - Top
2x 120mm 650-1800RPM PWM (SickleFlow)
Pre-installed Fans - Front
N/A
Pre-installed Fans - Rear
N/A
Pre-installed Fans - Bottom
N/A
Fan Support - Top
2x 120mm
Fan Support - Rear
1x 92mm
Fan Support - Bottom
2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)
Fan Support - Side
2x 120/140mm
Radiator Support - Top
N/A
Radiator Support - Rear
92mm (not compatible with vertical GPU installation)
Radiator Support - Bottom
120mm, 240mm, (recommended for custom loops only)
Radiator Support - Side
120mm, 140mm, 240mm, 280mm, (max width 141mm, not compatible with vertical GPU installation)
Clearance - CPU Cooler
76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)
Clearance - PSU
130mm
Clearance - GFX
L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
Dust Filters
Top, Bottom, Left side, Right side
Power Supply Support
SFX, SFX-L
Warranty
2 years
Weight
5.1 kg
Accessories
1x PCIe 3.0 x16 riser cable
Note
Single slot water-cooler GPUs or vertically mounted GPUs are recommended when using bottom radiator position, This product is only compatible for devices that support the PCI-E 3.0 specification. If you use this product with a motherboard that supports PCI-E 4.0, please enter into BIOS option and select PCI-E 3.0 before installation.
