Prezzo: € 125,90 +IVA
Disponibilità: 0
Specifications
80 PLUS® Certification
Platinum
Modular cables
Fully modular
Cable type
Modular 24-pin: Braided sleeve UltraFlex wire. Others: Flat UltraFlex wire
Fan type
Customized 140 mm FDB bearing Fractal Design Dynamic Series fan
Maximum operating temperature at full load
50°C
Semi-passive operation
Yes, user selectable (Zero RPM)
Sleep State Compliance
C6/C7
Warranty
10 years
Capacitors
Japanese
Protection features
Over voltage protection. Under voltage protection. Over power protection. Short circuit protection. Over current protection. Over temperature protection
Approvals & Certifications
CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE
Life expectancy (MTBF) at max output load
100,000 hours
Input voltage
100-240V AC
Input frequency
50-60 Hz
Input current
10A/5A
Number of 12V rails
1
PSU specification compliance
ATX12V 2.4 / EPS12V 2.92
Standby efficiency
ErP 2013 (<0.45W @230. VAC, 45 mA load on +5Vsb)
Unit measurements
150 x 150 x 86 mm
Unit weight (unit only)
1.665 kg
Connectors
ATX 24-pin
1
ATX12V 4+4 pin / EPS12V 8-pin
2
PCIe 6+2 pin
6
SATA
10
Peripheral
4
Cable configuration (length between connectors)
ATX 24-pin
600 mm
ATX12V 4+4 pin
700 mm
EPS12V 8-pin
600 mm
PCIe 6+2 pin
550+120 mm x2
SATA
400+120+120+120 mm & 650+120 mm
Peripheral
400+120+120+120
DC output
3.3 V
22 A
5 V
22 A
3.3 V and 5 V combined
120 W
12 V
71.6 A
-12 V
0.3 A
5 V Standby (+5 Vsb)
3 A
Total Power
860 W
Other
Package content
Ion+ PSU with protective bag, Modular cables in a convenient storage bag, Screw pack with Velcro cable ties, AC power cord (localized), User manual
Package dimensions (W x H x D)
325 x 110 x 210 mm
Package weight
2.975 kg
EAN
7340172701927
UPC
843276101923
Product code
FD-PSU-IONP-860P-BK
