Prezzo: € 96,96 +IVA
Disponibilità: 0
Processore
AM4 Socket:
Support for AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors
(Please refer "CPU Support List" for more information.)
Chipset
AMD B450
Memoria
2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
Architettura di memoria a doppio canale
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
* ECC function is limited if using an AMD Athlon™ 200-series APU.
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules
Supporta le memorie dotate di Profilo XMP
(Please refer "Memory Support List" for more information.)
Grafica integrata
Integrated Graphics Processor:
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
*Support for DisplayPort 1.2 version.
2 x HDMI ports, supporting a maximum resolution of 4096x2160@60 Hz(Note)
* Support for HDMI 2.0 version and HDCP 2.2.(Note)
* One of HDMI function is limited if using an AMD Athlon™ 200-series APU.
Support for up to 3 displays at the same time
Maximum shared memory of 16 GB
(Note) Actual support may vary by CPU.
Audio
Realtek® ALC1220-VB codec
Audio ad alta definizione
Audio a 2/4/5.1/7.1 canali
*To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
Supporto per S / PDIF
LAN
Intel® GbE LAN chip (10/100/1000 Mbit)
Wireless Communication module
Wi-Fi 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
Bluetooth 5
Support for 11ac 160 MHz wireless standard and up to 1.73 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
** Only support for Windows 10 64-bit.
Slot di Espansione
1 x PCI Express x16 slot, running at x16(Note)
(Lo Slot PCIEX16 è conforme allo standard PCI Express 3.0.)
1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
(Note) Actual support may vary by CPU.
Interfaccia di storage
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
4 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, and RAID 10
USB
Integrated in the APU:
4 x USB 3.1 Gen 1 ports on the back panel
Chipset:
2 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
2 x USB 3.1 Gen 1 ports available through the internal USB header
2 x USB 2.0/1.1 ports available through the internal USB header
Connettori Interni I/O
1 x 24-pin ATX main power connector
1 Connettore di Alimentazione ATX ad 8-pin
1 Connettore per Ventola della CPU
1 x Connettore per System Fan
1 x digital LED strip header
1 x CPU cooler LED strip/RGB LED strip header
4 Connessioni SATA 6Gb/s
1 x M.2 Socket 3 connector
1 x front panel header
1 Connettore per uscite Audio Frontali
1 x S/PDIF Out header
1 x speaker header
1 x USB 3.1 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
La funzione TPM è opzionale in base alla regolamentazione dei vari stati
1 x Clear CMOS jumper
1 x chassis intrusion header
Pannello Posteriore I/O
3 x audio jacks
1 x DisplayPort
2 x HDMI ports
2 x USB 3.1 Gen 2 Type-A ports (red)
4 x USB 3.1 Gen 1 ports
1 Porta RJ-45
2 x SMA antenna connectors (2T2R)
I/O Controller
iTE® I/O Controller Chip
Monitoraggio H/W
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS
1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Altre Caratteristiche
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@ BIOS ™
3D OSD
Auto Green
Support for Cloud Station
EasyTune
Fast Boot
Game Boost
Supporto alla tecnologia ON/OFF Charge
RGB Fusion
Smart Backup
Smart Keyboard
Smart TimeLock
Smart HUD
Smart Survey
System Information Viewer
USB Blocker
V-Tuner
Supporta il Q-Flash
Support for Xpress Install
Software in Bundle
Norton® Internet Security (OEM version)
cFosSpeed
Sistema Operativo
Support for Windows 10 64-bit
Support for Windows 7 64-bit
* To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
* Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
Caratteristiche Fisiche
Mini-ITX Form Factor; 17.0cm x 17.0cm
Note
Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
A causa delle diverse condizioni di supporto per Linux fornito da fornitori di chipset, scaricare il driver Linux dal sito web fornitori di chipset.
