Prezzo: € 55,90 +IVA
Disponibilità: 0
Dimensions radiator (l x w x d) 274 x 120 x 27 mm
Dimensions fan (l x w x d) 120 x 120 x 25 mm
Dimensions heat sink (l x w x d) 52 x 58 x 38 mm
Dimensions copper plate (l x w) 52 x 58 mm
Weight (retail) 1,53 kg
Weight (cooler + fan) 0,907 kg
Rated voltage 12V DC
Starting voltage 6V
Operating voltage range 10 - 14V
Rated current 0,22A (0,26A max.)
Input power 3W
Fan speed 1000 - 1780 rpm (+/- 10%)
Air flow 20,13 - 86,5 CFM (+/- 10%)
Air pressure 4,51 - 37,26 Pa
Fan noise level 19-35 dB(A) max.
Pump noise level <25 dB(A) max.
Bearing FDB - Fluid Dynamic Bearing
Fan connector 4 pin PWM
Cooler connector 3 pin
TDP (Thermal Design Power) 300W
Fan cable length each ca. 30 cm
Tube length each ca. 31 cm
Number of fan wings each 7 wings
Material Radiator: aluminium
Heat sink: copper / plastic
Fan: plastic
Tubes: plastic
Working temp -10℃ ~ 60℃
Storage temp -20℃ ~ 70℃
Mark of conformity CE
Colour black
Barcode 4260070125324
Manufacturer code LC-CC-240-LiCo
