MSI MAG X570S Tomahawk WiFi MAX - Scheda prodotto

MSI MAG X570S Tomahawk WiFi MAX

MSI MAG X570S Tomahawk WiFi MAX
Ingrandisci immagine
7D54-001R
Codice prodotto: MSI221

Prezzo: € 215,90 +IVA
Disponibilità: 0

Descrizione prodotto

Processor

Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series and 2000 G-Series desktop processors1
Supports Socket AM4

Please go to msi.com to get the newest support status as new processors are released.

See supported processors
Chipset

AMD X570 Chipset
Memory

4x DDR4 memory slots, support up to 128GB
Supports 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC1
Max overclocking frequency by A-XMP OC mode:
For Ryzen™ 5000 G-Series & 4000 G-Series processors
1DPC 1R Max speed up to 5100 MHz
1DPC 2R Max speed up to 4000 MHz
2DPC 1R Max speed up to 4266 MHz
2DPC 2R Max speed up to 3600 MHz
For Ryzen™ 5000 Series & 3000 Series processors
1DPC 1R Max speed up to 5100 MHz
1DPC 2R Max speed up to 3866 MHz
2DPC 1R Max speed up to 4000 MHz
2DPC 2R Max speed up to 3600 MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory

Please refer to www.msi.com for more information on compatible memory.

See supported memory
Expansion Slot

Supports PCIe 4.0 / PCIe 3.0 specification
PCIe 4.0 is available only on AMD Ryzen™ 5000 Series and 3000 Series desktop processors
1x PCIe x16 slot (From processor)
PCI_E1 supports PCIe 4.0/ 3.0 x16
1x PCIe x16 slot (From X570 chipset)
PCI_E3 supports PCIe 4.0/ 3.0 x4
2x PCIe 3.0 x1 slots (From X570 chipset)

Multi-GPU

Supports AMD CrossFire™ Technology

Onboard Graphics

1x HDMI 2.1 port, supports a maximum resolution of 4K 60Hz 1 2

Available only on processors featuring integrated graphics.
Graphics specifications may vary depending on the CPU installed.

Storage

6x SATA 6Gb/s ports (from AMD X570 Chipset)
2x M.2 slots (Key M)
Support up to PCIe 4.0 for AMD Ryzen™ 5000 Series and 3000 Series desktop processors
Support up to PCIe 3.0 for AMD Ryzen™ 5000 G-Series, 4000 G-Series, 3000 G-Series, 2000 Series and 2000 G-Series desktop processor
Supports up to SATA 6Gb/s
M2_1 slot (from Processor)
Support 2280/22110 storage devices
M2_2 slot (from AMD X570 Chipset)
Supports 2242/ 2260/ 2280 storage devices

RAID

Supports RAID 0, RAID 1 and RAID 10

USB
AMD X570 Chipset

3x USB 3.2 Gen 2 10Gbps ports (2 Type-A ports on the back panel, 1 Type-C internal connector)
4x USB 3.2 Gen 1 5Gbps ports available through the internal USB 3.2 Gen 1 5Gbps connectors
6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)

AMD Processor

2x USB 3.2 Gen 2 10Gbps ports on the back panel (Type-A & Type-C)
2x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel

Audio
Realtek® ALC4080 Codec

7.1-Channel High Definition Audio
Supports S/PDIF output

LAN

1x Realtek® 8125B 2.5Gbps LAN Controller

Wireless LAN & Bluetooth
Intel® Wi-Fi 6E AX210

The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz 1 (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.22, FIPS, FISMA

Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in WIN10 21H1.
Bluetooth 5.2 will be ready in WIN10 21H1.

Internal connectors

1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
1x 4-pin ATX 12V power connector
6x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4 USB 3.2 Gen 1 5Gbps ports)
1x USB 3.2 Gen 2 10Gbps Type-C port
1x 4-pin CPU fan connector
1x 4-pin water-pump connector
4x 4-pin system fan connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Serial port connector
1x Chassis Intrusion connector

LED Feature

2x 4-pin RGB LED connectors
2x 3-pin RAINBOW LED connectors
4x EZ Debug LED
1X EZ LED Control switch

Back panel ports

PS/2 Mouse / Keyboard
Wi-Fi Antenna
USB 3.2 Gen 1 5Gbps (Type-A)
USB 3.2 Gen 2 10Gbps (Type-A)
2.5G LAN Port
HD Audio Connectors
Flash BIOS Button
USB 2.0 Port
HDMI 2.1 Port
USB 3.2 Gen 2 10Gbps (Type-C)
USB 3.2 Gen 2 10Gbps (Type-A)
Optical S/PDIF OUT

MAG X570S TORPEDO MAX back panel ports
Dimensions

ATX Form Factor
12 in. x 9.6 in. (30.5 cm x 24.4 cm)

Operating System

Support for Windows® 10 64-bit
Box content
MAG X570S Tomahawk MAX box content

MSI® does not guarantee the risks or damages caused by changing the cover.
These pictures are for reference only and may vary without notice.

All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Please consult the product specifications page for full details.Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with your local supplier for exact offers.
