MSI MEG X399 CREATION - Scheda prodotto

MSI MEG X399 CREATION

MSI MEG X399 CREATION
Ingrandisci immagine
7B92-001R su ord. 3gg
Codice prodotto: MSI197

Prezzo: € 413,70 +IVA
Disponibilità: 0

Descrizione prodotto

Processor

Supports 1st and 2nd Gen AMD® RYZEN™ THREADRIPPER™ Series Processors for SocketTR4

See supported processors
Chipset

AMD® X399 Chipset
Memory

8 x DDR4 memory slots, support up to 128GB
Supports DDR4 3600+(OC)/ 3466(OC)/ 3333(OC)/ 3200(OC)/ 3066(OC)/ 2933(OC)/ 2800(OC)/ 2667(OC)/ 2400/ 2133 MHz
Quad channel memory architecture
Supports ECC UDIMM memory

See supported memory
Slots

2x PCIe 3.0 x16 slots (PCIE_1, PCIE_4)
2x PCIe 3.0 x8 slots (PCIE_3, PCIE_5)
1x PCIE 2.0 x1 Slot

Multi-GPU

Supports 3-Way NVIDIA® SLI™ Technology
Supports 3-Way AMD® CrossFire™ Technology

Storage
AMD® X399 Chipset

8 x SATA 6Gb/s ports

AMD® CPU

3 x M.2 ports (Key M)
Supports up to PCIe 3.0 x4 and SATA 6Gb/s
M2_1, M2_3 slots support 2242/ 2260 /2280 storage devices
M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices

RAID
AMD® X399 Chipset

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

USB
ASMedia® ASM3142 Chipset

1x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port available through the internal USB connector

AMD® X399 Chipset

1x USB 3.1 Gen1 (SuperSpeed USB) Type-A port on the back panel
1x USB 3.1 Gen1 (SuperSpeed USB) Type-C port on the back panel
4x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connectors
4x USB 2.0 (High-speed USB) ports available through the internal USB connectors

AMD® CPU

8x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel

Audio
Realtek® ALC1220 Codec

7.1-Channel High Definition Audio
Supports S/PDIF output

LAN

2 x Intel® I211AT Gigabit LAN controllers

WiFi & Bluetooth

Intel® Wireless-AC 9260 card
Supports Wi-Fi 802.11 ac, 2x2, Dual Band, (2.4GHz, 5GHz) up to 1.73 Gbps speed.
Supports Bluetooth® 5

Internal connectors

1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connector
1x flat 4-pin ATX 12V power connector
8x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
1x USB 3.1 Gen2 Type-C port
1x 4-pin CPU fan connector
1x 4-pin Water Pump connector
5x 4-pin system fan connectors
3x 4-pin extend fan connectors
2x Front panel connectors
1x Front panel audio connector
2x 5050 RGB LED strip 12V connector (JRGB1~2)
1x WS2812B Individually Addressable RGB LED strip 5V connector (JRAINBOW1)
1x CORSAIR connector (JCORSAIR1)
1x TPM module connector
3x 2-pin Thermal Sensors connectors

Back panel ports

Clear CMOS Button
USB 3.1 Gen1 Ports
USB 3.1 Gen1 Ports
Intel® WiFi/ Bluetooth Module
Dual Intel® LAN Ports
HD Audio Connectors
Flash BIOS Button
USB 3.1 Gen1 Ports
AMD Turbo USB 3.1 Gen 1 Type A + C
Optical S/PDIF-Out

MSI meg x399 creation back panel ports
Dimensions

12 in. x 10.7 in. (30.4 cm x 27.2 cm)
E-ATX Form Factor

Mounting

9 mounting holes
Operating System

Support for Windows® 10 64-bit

Box content
MSI MEG X399 CREATION box content

All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Please consult the product specifications page for full details.Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with your local supplier for exact offers.
