Samsung 970 EVO 500GB SSD M.2 PCIe x4 NVMe - Scheda prodotto

Samsung 970 EVO 500GB SSD M.2 PCIe x4 NVMe

Samsung 970 EVO 500GB SSD M.2 PCIe x4 NVMe
Ingrandisci immagine
MZ-V7E500BW EAN: 8801643205263 R:3400Mhz W:2300Mhz
Codice prodotto: SAM415

Prezzo: € 109,90 +IVA
Disponibilità: 2 (dal 17 dicembre: 10)

Descrizione prodotto

Form Factor

M.2

Capacity

250 GB, 500 GB, 1,024 GB, 2,048 GB

Sequential Read Speed

Max. 3,500 MB/s

Sequential Write Speed

Max. 2,500 MB/s
SHOW MORE SPECS layer close
MORE SPECS
Model Code (Capacity)1)

MZ-V7E250BW (250 GB)
MZ-V7E500BW (500 GB)
MZ-V7E1T0BW (1,024 GB)
MZ-V7E2T0BW (2,048 GB)

General Feature

Application

Client PCs
FORM FACTOR

M.2 (2280)
INTERFACE

PCIe Gen 3.0 x4, NVMe 1.3
DIMENSION (WxHxD)

80.15 X 22.15 X 2.38 (mm)
WEIGHT

Max. 8.0g
STORAGE MEMORY

Samsung V-NAND 3-bit MLC
CONTROLLER

Samsung Phoenix Controller
CACHE MEMORY

512 MB Low Power DDR4 SDRAM (250 GB, 500 GB)
1 GB Low Power DDR4 SDRAM (1,024 GB)
2 GB Low Power DDR4 SDRAM (2,048 GB)

Special Feature

TRIM Support

Yes
S.M.A.R.T Support

Yes
GC (GARBAGE COLLECTION)

Auto Garbage Collection Algorithm
ENCRYPTION SUPPORT

AES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted drive)
WWN SUPPORT

Not Supported
DEVICE SLEEP MODE SUPPORT

Yes

Performance2)

SEQUENTIAL READ

250 GB, 500 GB, 1,024 GB: Up to 3,400 MB/s
2,048 GB: Up to 3,500 MB/s
SEQUENTIAL WRITE

250 GB: Up to 1,500 MB/s
500 GB : Up to 2,300 MB/s
1,024 GB, 2,048 GB: Up to 2,500 MB/s
RANDOM READ (4KB, QD32)

250 GB: Up to 200,000 IOPS
500 GB: Up to 370,000 IOPS
1,024 GB, 2,048 GB: Up to 500,000 IOPS
RANDOM WRITE (4KB, QD32)

250 GB: Up to 350,000 IOPS
500 GB, 1,024 GB: Up to 450,000 IOPS
2,048 GB: Up to 480,000 IOPS
RANDOM READ (4KB, QD1)

Up to 15,000 IOPS
RANDOM WRITE (4KB, QD1)

Up to 50,000 IOPS

Environment

AVERAGE POWER CONSUMPTION
(System Level)3)

250 GB: Average 5.4 W Maximum 9.0 W
500 GB: Average 5.7 W Maximum 10.0 W
1,024 GB, 2,048 GB: Average 6.0 W Maximum 10.0 W
(Burst mode)
POWER CONSUMPTION (IDLE)3)

Max. 30mW
POWER CONSUMPTION (Device Sleep)

Max. 5mW
ALLOWABLE VOLTAGE

3.3 V ± 5 % Allowable voltage
RELIABILITY (MTBF)

1.5 Million Hours Reliability
OPERATING TEMPERATURE

0 - 70 ℃
Shock

1,500 G & 0.5 ms (Half sine)

Accessories

INSTALLATION KIT

N/A

Software

MANAGEMENT SW

Magician Software for SSD management

Warranty

MZ-V7E250BW (250 GB)

5 Years or 150 TBW
MZ-V7E500BW (500 GB)

5 Years or 300 TBW
MZ-V7E1T0BW (1,024 GB)

5 Years or 600 TBW
MZ-V7E2T0BW (2,048 GB)

5 Years or 1,200 TBW
