| Ingrandisci immagine |
Prezzo: € 53,00 +IVA
Disponibilità: 0
Processore Qualcomm Atheros 560MHz CPU, MIPS 74Kc
Memoria 64MB DDR2 RAM, 8MB Flash
Interfaccia 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)
1 Grounding Terminal
1 Reset Button
Alimentazione Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
Voltage range: 16-27VDC
Consumo energetico 10.5 Watts Max
Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.
Dimensioni ( L x P x A ) 224 x 79 x 60 mm
Tipo di antenna Built-in 9dBi 2x2 Dual-polarized Directional Antenna
Beam Width: 65° (H-Plane) / 35° (E-Plane)
Note: For more details, please refer to datasheet
Sicurezza 15KV ESD Protection
6KV Lightning Protection
Enclosure Outdoor ASA stabilized plastic material
IPX5 waterproof Certification
CARATTERISTICHE WIRELESS
Standard wireless IEEE 802.11b/g/n (with Pharos MAXtream disabled)
Protocollo proprietario TDMA Mode (with Pharos MAXtream enabled)
Velocità wireless Up to 300Mbps (40MHz,Dynamic)
Up to 144.4Mbps (20MHz,Dynamic)
Up to 72.2Mbps (10MHz,Dynamic)
Up to 36.1Mbps (5MHz,Dynamic)
Frequenza 2.4~2.483GHz
Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.
Potenza di trasmissione <20dBm EIRP (normativa CE)
CARATTERISTICHE SOFTWARE
Configurazioni wireless Pharos MAXtream TDMA Technology
802.11b/g/n Modes
Selectable Channel Width: 5/10/20/40MHz
Automatic Channel Selection
Transmission Power Control
Dynamic Frequency Selection (DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging (AP mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
> Beacon Interval/RTS Threshold/Fragmentation
>Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Gestione Discovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System Log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server
Tool di sistema Wireless Signal Quality Indicators:
Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute
Ottimizzazioni di sistema Optimized IGMP Snooping/Proxy for multicast applications
Hardware watch dog
CARATTERISTICHE ADATTATORE POE
Dimensioni ( L x P x A ) 110*57*33.5mm
Input Current 0.8A Max @ 100VAC
Input Voltage 100VA~240VAC @ 50Hz~60Hz
Output 24VDC, 1.0A Max
+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Efficienza >80%
Output Voltage 24VDC(+4,5pins; -7,8pins)
Input 100-240VAC, 50/60Hz
Indicatori di carica LED 0~0.8A: Green
0.8A~1.0A: Red
Certificazioni CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
Interfacce 1 AC Jack with Earth Ground
1 10/100/1000Mbps Shielded Ethernet Port (Power + Data)
1 10/100/1000Mbps Shielded Ethernet Port (Data)
Tasto Remote Reset Button
ALTRO
Certificazione CE, FCC, RoHS, IPX5
Contenuto della confezione Outdoor Wireless CPE
24V 1A Passive PoE Adapter
Pole Mounting Straps
AC Power Cord
Installation Guide
Requisiti di sistema Nessuno.
Ambiente Operating Temperature: -40°C~70°C (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
