Prezzo: € 20,90 +IVA
Disponibilità: 0
CARATTERISTICHE HARDWARE
Interfaccia 4 10/100Mbps LAN ports
1 10/100Mbps WAN port
1 USB 2.0 port
Tasto WPS/Reset Button
Wireless On/Off Switch
Power On/Off Button
Antenna 2 × 2.4GHz Antennas
1 × 5GHz Antenna
Alimentatore esterno 12VDC /1A
Dimensioni ( L x P x A ) 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
Tipo di antenna Two dual band fixed antennas
CARATTERISTICHE WIRELESS
Standard wireless IEEE 802.11ac/n/a 5GHz
IEEE 802.11b/g/n 2.4GHz
Frequenza 2.4GHz and 5GHz
Signal rate 5GHz: Up to 433Mbps
2.4GHz: Up to 300Mbps
Sensibilità di ricezione 5GHz
11a 6Mbps: -91dBm, 11a 54Mbps: -74dBm
11ac HT20: -66dBm, 11ac HT40: -64dBm, 11ac HT80: -61dBm,
11n HT20: -71dBm, 11n HT40: -69dBm
2.4GHz
11g 54M: -76dBm
11n HT20: -74dBm, 11n HT40: -71dBm
Funzionalità wireless Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Sicurezza wireless 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption
Potenza di trasmissione CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
FCC:
<30dBm
CARATTERISTICHE SOFTWARE
QoS (Quality of Service) WMM, Bandwidth Control
Gestione Access Control
Local Management
Remote Management
Port forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, Comexe, NO-IP
VPN pass-through PPTP, L2TP, IPSec
Gestione accessi Parental Control, Local Management
Control, Host List,
Access Schedule, Rule Management
Firewall DoS, SPI Firewall
IP Address Filtering/MAC Address Filtering/Domain Filtering
IP and MAC Address Binding
Protocolli Supports IPv4 and IPv6
Condivisione USB Support Samba(Storage)/ FTP Server/Media Server/Printer Server
Rete ospiti 2.4GHz guest network × 1
5GHz guest network × 1
ALTRO
Certificazione CE, FCC, RoHS
Contenuto della confezione AC750 Wireless Dual Band Router Archer C20
2 Fixed Antennas
Power Supply Unit
Resource CD
Ethernet Cable
Quick Installation Guide
Dimensioni scatola ( L x P x A ) 11.2 x 8.8 x 3.6 in. (285x223x91mm)
Requisiti di sistema Windows 10/8.1/8/7/Vista/XP, Mac OS or Linux-based operating system
Ambiente Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
