Ingrandisci immagine |
Prezzo: € 26,90 +IVA
Disponibilità: 0
Interfaccia 5 10/100Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Numero ventole Fanless
Alimentatore esterno External Power Adapter(Output: 48VDC / 1.25A)
Porte PoE Standard: 802.3 af compliant
PoE Ports: Port1- Port4
Power Supply: 58W
Tabella ARP 2K
Capacità di switching 1Gbps
Dimensioni ( L x P x A ) 3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm)
Distanza di trasmissione Store-And-Forward
Max Power Consumption 1.678W (max. no PD connected)
64.82W (max. with 58w PD connected)
Max Heat Dissipation 5.73BTU/h(no PD connected)
221.17BTU/h(with 58W PD connected)
CARATTERISTICHE SOFTWARE
Metodo di trasmissione Store-And-Forward
Funzionalità avanzate Compatible With IEEE 802.3af Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode
ALTRO
Certificazione FCC, CE, RoHS
Contenuto della confezione TL-SF1005P, Power Adapter, User Guide
Ambiente Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90%RH non-condensing
Storage Humidity: 5%~90%RH non-condensing
